Please Note: We no longer stock these products, please see our Point to Point products for an alternative solution.

Bridgewave AR60 60GHz AdaptRate Link

The BridgeWave's AR60 60GHz is designed for high-bandwidth applications and provides wireless gigabit performance with robust wireless network security features. The BridgeWave AR60 links extend network operator fiber to provide high-capacity access and backhaul, as well as extendingenterprise LANs between buildings and sites.

BridgeWave AR60 Key Features:

Full rate, full duplex, Gigabit or Fast Ethernet
License-free operation in the U.S. and Canada
AdaptRate switching overcomes rain downpours
AdaptPath provides secondary path switching for maximum service availability
Interference-free operation enabling high-density deployments
Low latency for fiber-equivalent performance
Forward Error Correction provides maximum link range

Wireless Virtual Fiber Solutions for:

Enterprise Server centralization, remote data storage andbackup, leased line replacement.
Healthcare Secure, HIPAA-compliant connectivity, medicaloffice, lab network access, real-time imaging &records, application connectivity.
Education High-performance campus connectivity, Wi-Fiand security camera backbone.
Government/Municipalities Video surveillance systems, traffic control andmonitoring, Wi-Fi/4.9GHz backhaul.
Service Provider High-capacity business services, fiberextensions, cellular/Wi-Fi/WiMAX backhaul,redundant fiber overlays, mesh.
Mobile Backhaul Future-proof full-rate gigabit backhaul for nextgeneration 4G/LTE/WiMAX backhaul.

BridgeWave AR60 60GHz AdaptRate Link Technical Specification

Security

Highly secure narrow beamwidth antennas
Secure Management software option provides HTTPS management accessand RADIUS authentication (see Advanced Security datasheet)
AES Encryption hardware option provides the ultimate level of full line-ratedata protection (see Advanced Security datasheet)

Reliability

Rigorous HALT/HASS testing; 28-Year MTBF
Up to 99.999%, carrier-grade availability

Ease-of-Use

Connects directly to standard network equipment
All-outdoor, compact design
Low voltage power cabling
Rapid & flexible deployment
Embedded web and SNMP based network management agent

Operating Mode

1000 Mbps full-duplex, 100 Mbps full-duplex, 1000/100 Mbps AdaptRate
AdaptRate andAdaptPathSwitching
Normal operation: 1000 Mbps / Path fade mode: 100 Mbps / Secondary link: Dependant of user supplied product capability
Switching time: < 50 milliseconds
AdaptRate switch point: -57 dBm / -59 dBm
AdaptPath switch point: Configurable
Data Rate 1000 Mbps full duplex 100 Mbps full duplex 1000 Mbps full duplex 100 Mbps full duplex
Latency < 40 uSec < 220 uSec < 40 uSec < 220 uSec
Link Budget 150.5 dB @ 1012 BER 161.5 dB @ 1012 BER 163.5 dB @ 1012 BER 174.5 dB @ 1012 BER 152.5 dB @ 106 BER 163.5 dB @ 106 BER 165.5 dB @ 106 BER 176.5 dB @ 106 BER
RF Interface 58.1 GHz/62.9 GHz (FDD), digitally modulated (BFSK) with forward error correction RS(204,188)
1.4 GHz bandwidth 285 MHz bandwidth 1.4 GHz bandwidth 285 MHz bandwidth
Min. link distance 65 ft (20 m) Min. link distance 330 ft (100 m)

256Bit AES Encryption option (see Advanced Security datasheet for details)

Ethernet 1000baseSX with LC connectors up to 270 m 62.5/125µm MMF, or 500 m 50/125µm MMF
Interfaces 10/100baseTX with RJ45 connector (with integral surge suppressor) up to 100 m CAT5 cable
Maximum Ethernet frame length: 1632 bytes
Management Webbased (HTML) embedded management agent: setup, security, status, statistics, software update
Secure Management Access (see Advanced Security datasheet for details)
SNMP support: MIBII and BridgeWave enterprise MIB
Voltmeter test points: Receive Signal Level and Link Quality
RADIUS Authentication, SysLog support
Power Supplied 100 – 240 VAC input, +24 VDC output, indoor rated power supply (0°C to +40°C). 45 watts max. consumption
Max. cable length: 650 ft (200 m) with 12AWG 400 ft (125 m) with 14AWG, stranded wires highly recommended (surge suppressor required)
Size Radio/antenna unit: 12 w * 12 h * 6 d (in) / 30 w * 30 h * 15 d (cm) Radio with antenna and mount: 24 w * 24 h * 20 d (in) / 62 w * 62 h * 50 d (cm)
Weight Radio with antenna and mount: 22 lbs (10 kg) Radio with antenna and mount: 38.5 lbs (17.5 kg)
Environmental Operating temperature: 33 to +55°C (27 to 131°F)
Operating altitude: 14,764 ft maximum (4,500 m)
Wind Loading 50 lbs. force @ 100 MPH 202 lbs. force @ 125 MPH
Regulatory Safety: UL Listed, CE Mark, EN60950, meets FCC 1.1310 general population RF MPE limits
