WIRELESS

• Wireless mode: 802.11b/g/n/ac Wave 2 (Wi-Fi 5) with data transmission rates up to 867 Mbps (Dual Band, MU-MIMO)
• Wi-Fi security:
  • WPA2-EAP/WPA3-EAP Mixed Mode, WPA3-EAP, WPA2-PSK/WPA3-SAE Mixed Mode, WPA3-SAE, OWE, WPA-PSK/WPA2-PSK Mixed Mode, WPA2-PSK, WPA2-EAP; AES-CCMP, TKIP, Auto Cipher modes, isolate clients
• SSID/ESSID: ESSID stealth mode (Hide SSID)
• Wi-Fi users: Up to 100 simultaneous connections
• Wireless mesh/roaming: Fast roaming (802.11r)
• Wireless MAC filter: Whitelist, blacklist
• Wireless QR code generator: Once scanned, a user will automatically enter your network without needing to input login information.

ETHERNET

• Ethernet: 1 x RJ45 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover

NETWORK

• Network protocols: TCP, UDP, IPv4, IPv6, ICMP, HTTP, HTTPS, SSL/TLS, ARP, SSH, DHCP client, SNMP

SECURITY

• Authentication: SSH key based, HTTPS, CLI, IP & Login attempts block
• VLAN: Tag-based VLAN separation

MONITORING & MANAGEMENT

• WEB UI: HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, event log, system log, kernel log
• FOTA: Firmware update from server, automatic notification
• SSH: SSH (v1, v2)
• JSON-RPC: Management API over HTTP/HTTPS
• RMS: Teltonika Remote Management System (RMS)

SYSTEM CHARACTERISTICS

• CPU: MediaTek, Dual-Core, 880 MHz, MIPS 1004Kc
• RAM: 256 MB, DDR3
• FLASH storage: 16MB, SPI NOR Flash

FIRMWARE / CONFIGURATION

• WEB UI: Update FW from file, check FW on server, configuration profiles, configuration backup
• FOTA: Update FW
• RMS: Update FW/configuration for multiple devices at once
• Keep settings: Update FW without losing current configuration

FIRMWARE CUSTOMISATION

• Operating system: RutOS (OpenWrt based Linux OS)
• Supported languages: Busybox shell, Lua, C, C++
• Development tools: SDK package with build environment provided
• GPL customization: You can create your own custom, branded firmware and web page application by changing colours, logos, and other elements in our firmware to fit your or your clients’ needs.

POWER

• Connector: RJ45 Socket
• Input voltage range: 44.0 – 57.0 V
• PoE standards: 802.3af PoE Class 1
• Power consumption: Idle: < 4 W / Max: < 5.5 W

PHYSICAL INTERFACES

• Ethernet: 1 x RJ45 port, 10/100/1000 Mbps
• Status LEDs: 1 x Power LED (can be turned off from web-UI)
• Antennas: 2 x Internal for 2.4 GHz Wi-Fi, 2 x Internal for 5 GHz Wi-Fi
• Antennas specifications:
  • 2 x 2400 - 2500 MHz, 50 Ω, VSWR <2.7, gain < 4.9 dBi, omnidirectional
  • 2 x 5150 - 5850 MHz, 50 Ω, VSWR <2, gain < 5.02 dBi, omnidirectional
• Reset: Reboot/User default reset/Factory reset button

PHYSICAL SPECIFICATION

• Casing material: UV stabilized plastic
• Dimensions: Ø 158 mm x 30 mm
• Weight: 190 g
• Mounting options: AP Mounting Bracket (for ceiling mount)

OPERATING ENVIRONMENT

• Operating temperature: -40 °C to 75 °C
• Operating humidity: 10% to 90% non-condensing
• Ingress Protection Rating: IP30

See datasheet attached for full tech spec.
