MOBILE

• Mobile module
  • LTE Cat M1 /Cat NB1, NB2 / EGPRS (simultaneous operation of cellular and GNSS connectivity is not supported)
• SIM switch
  • 2 SIM cards, auto-switch cases: weak signal, data limit, SMS limit, on roaming, no network, network denied, data connection fail
• Status
  • Signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, Bytes sent/received, connected band, IMSI, ICCID
• SMS
  • SMS status, SMS configuration, send/read SMS via HTTP POST/GET, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP
• Black/White list
  • Operator black/white list
• Band management
  • Band lock, Used band status display
• SIM idle protection service
  • When working with devices with two SIM slots, the one not currently in use will remain idle until the device switches to it, meaning that no data is used on the card until then
• APN
  • Auto APN
• Bridge
  • Direct connection (bridge) between mobile ISP and device on LAN
• Passthrough
  • Gateway assigns its mobile WAN IP address to another device on LAN

ETHERNET

• Ethernet
  • 1 x ETH port, 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover

NETWORK

• Routing
  • Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy based routing
• Network protocols
  • TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL)
• VoIP passthrough support
  • H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
• Connection monitoring
  • Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspection
• Firewall
  • Port forward, traffic rules, custom rules
• Firewall status page
  • View all your Firewall statistics, rules, and rule counters
• Ports management
  • View device ports, enable and disable each of them, turn auto-configuration on or off, change their transmission speed, and so on
• Network topology
  • Visual representation of your network, showing which devices are connected to which other devices
• Hotspot
  • Captive portal (Hotspot), internal/external Radius server, SMS authorization, internal/external landing page, walled garden, user scripts, URL parameters, user groups, individual user or group limitations, user management, 9 default customizable themes and option to upload and download customized hotspot themes
• DHCP
  • Static and dynamic IP allocation, DHCP Relay
• QoS / Smart Queue Management (SQM)
  • Traffic priority queuing by source/destination, service, protocol or port, WMM, 802.11e
• DDNS
  • Supported >25 service providers, others can be configured manually
• Network backup
  • VRRP, Wired options, each of which can be used as an automatic Failover, Mobile
• SSHFS
  • Possibility to mount remote file system via SSH protocol

SECURITY

• Authentication
  • Pre-shared key, digital certificates, X.509 certificates, TACACS+, Radius, IP & Login attempts block
• Firewall
  • Pre-configured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI; DMZ; NAT; NAT-T
• Attack prevention
  • DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks)
• VLAN
  • Tag-based VLAN separation
• Mobile quota control
  • Mobile data limit, customizable period, start time, warning limit, phone number
• WEB filter
  • Blacklist for blocking out unwanted websites, Whitelist for specifying allowed sites only
• Access control
  • Flexible access control of SSH, Web interface, CLI and Telnet

See datasheet attached for full tech spec.
