Ubiquiti UniFi CloudKey Plus SSD (UCK-G2-SSD)
The Ubiquiti UniFi CloudKey Plus SSD, a Compact UniFi Console offers powerful, multi-application site management and includes the full UniFi application suite for comprehensive device management. It also comes with a pre-installed 1TB SSD, providing ample storage for managing network data and devices.
Ubiquiti UniFi CloudKey Plus SSD Key Features
- Includes full UniFi application suite for device management
- Pre-installed 1TB SSD
- Connect and power using PoE
- Optional USB-C power with Quick Charge 2.0/3.0 compliant adapter only
- Bluetooth for instant setup
For enhanced data protection, the system supports RAID storage technology, ensuring reliability and security of stored video footage. Additionally, it includes two hot-swappable power supply units (PSUs) for power redundancy, minimising downtime and maintaining continuous operation in case of a PSU failure.
High Performance Cloud Key Gen2 Plus
Featuring SDN Controller, UniFi Protect, 1 TB Storage, Up to 20 cameras, Expansion Support and Bluetooth
Responsive Controller Experience
4x Faster Performance than the original Cloud Key
Multiple Controllers in Cloud Key Gen2 Plus
Easily scale your security system with up to 20 cameras and up to 50 UniFi Devices. Store your data in the Cloud Key, not the cloud, for maximum security with Easy-to-use UniFi Controller Interface
Versatile Rack-mount Accessory
The Cloud Key G2 and Cloud Key G2 Plus lock securely into the back of the Rack Mount Accessory for a clean and secure installation
UniFi Protect System
Ubiquiti UniFi CloudKey Plus SSD - Technical Specifications
Mechanical
- Dimensions: 131.2 x 27.1 x 134.2 mm (5.2 x 1.1 x 5.3")
- Weight: 560 g (1.2 lb)
- Enclosure material: Anodised aluminum
Hardware
- Processor: Octa-core Arm® Cortex®-A53 based chip
- Management interface: Ethernet, Bluetooth
- Networking interface: (1) GbE RJ45 port
- Memory:
- SSD capacity: 1 TB 2.5" SATA SSD (user-upgradeable*)
- *CloudKey+ only supports drives that can operate on 5V power. Drives that require additional power are not supported.
- Power method: PoE, Quick charge 2.0/3.0 power adapter, 9V DC, 2A
- Max. power consumption: 9.6W
- Display: 1.42" gray-scale OLED
- LEDs:
- Buttons:
- (1) Power
- (1) Factory reset
- Ambient operating temperature: 0 to 35° C (32 to 104° F)
- Ambient operating humidity: 20 to 80% noncondensing
- Certifications: FCC, CE, IC
Capacity
- HD cameras: 24
- 2K cameras: 14
- 4K cameras: 8
Assumes the UCK-G2-SSD is dedicated to UniFi Protect only. If it’s also running UniFi Network, your maximum camera limit will be lower.
