Ubiquiti UniFi Gate Hub - Technical Specifications

Mechanical

• Dimensions: 175 x 126 x 26 mm (6.9 x 5 x 1")
• Weight: 460 g (1 lb)
• Enclosure material: Polycarbonate
• Mounting: Din-rail (Included)

Hardware

• Networking interface: (5) 10/100/1000 Base-T
• Power method: PoE++, UL 294 Power-limited Class 2 PSU, UL 60950-1/62368-1 LPS/PS2 PSU
• Max. power consumption: Without PoE output: 22W, With PoE output: 50W, PoE input 50V DC, 1A, PoE output PoE passthrough, (4) PoE, 50V DC, Max. 28W
• LEDs: White/blue
• Button: (1) Factory-reset
• Digital input: Gate exit request, gate position, side door exit request, side door position, emergency
• Dry output: relay (2) Operator: rated 30V DC, up to 1A, (1) Aux: rated 30V DC, up to 1A
• Output relay Side door lock: 12V DC, up to 1A
• Recommend max. cable length

	18 AWG UACC-Cable-DoorLockRelay length	20 AWG length	22 AWG length	24 AWG length
UA-Lock-Electric (400mA)	100 m (328 ft)	66 m (217 ft)	42 m (138 ft)	25 m (82 ft)
UA-Lock-Magnetic-270kg (800mA)	46 m (151 ft)	30 m (98 ft)	20 m (66 ft)	12 m(29 ft)
UA-Lock-Magnetic-540kg (500mA)	80 m (262 ft)	51 m (167 ft)	32 m (105 ft)	20 m (66 ft)
Other locks(1A)	36 m (118 ft)	24 m (79 ft)	15 m (49 ft)	9 m (30 ft)

Operating environment: Indoor use only with device itself, Outdoor use with waterproof junction box

Ambient operating temperature: -30 to 60° C (-22 to 104° F)

Ambient operating humidity: 5 to 90% noncondensing

Software information: The software version of a product can be checked at https://unifi.ui.com

UL 294 level: Destructive attack: Level I, Line security: Level I, Endurance: Level I, Standby power: Level I

UL 294 statement: Compliance with IEEE 802.3 specifications was not verified as part of UL 294. The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits.

PoE cabling requirements: Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site.The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm 2 ) for patch cords; 24 AWG (0.21 mm 2 ) for horizontal or riser cable.

CAN/ULC-60839-11-1 Grade: Grade assignment: I

Certifications: CE, FCC, IC, UL 294, CAN/ULC-60839-11-1

Document number, and issue date and/or revision level: UA-Hub-Gate, V01
