Ubiquiti UniFi WiFi 7 Pro Access Point (U7-Pro)
The Ubiquiti UniFi U7-Pro is a state-of-the-art ceiling-mounted WiFi 7 access point engineered for large-scale environments with high demands for wireless connectivity. Its support for WiFi 7 and 6 GHz frequencies ensures a robust and interference-free WiFi experience, essential for modern networks dealing with bandwidth-intensive applications. With six spatial streams, the U7-Pro efficiently manages multiple data streams concurrently, guaranteeing seamless and high-speed performance even in densely populated areas.
Ubiquiti UniFi U7 Pro Key Features:
- WiFi 7 with 6 GHz support
- 140 m² (1,500 ft²) coverage
- 300+ connected devices
- Powered using PoE+
- 2.5 GbE uplink
One of the key strengths of the U7-Pro is its ability to provide reliable connectivity for over 300 connected devices within a coverage area of up to 140 square meters (1,500 square feet). This makes it an excellent choice for environments such as offices, schools, or retail spaces where numerous devices need reliable WiFi access simultaneously.
Moreover, the U7-Pro's Power over Ethernet Plus (PoE+) support streamlines installation by combining data connectivity and power delivery into a single Ethernet cable, reducing clutter and simplifying maintenance. Coupled with its 2.5 Gigabit Ethernet uplink, the U7-Pro ensures high throughput and seamless performance, making it an ideal solution for organizations seeking powerful and scalable WiFi solutions for their network infrastructure.
This ceiling-mounted WiFi 7 access point is designed to deliver exceptional performance in demanding, large-scale environments. With 6 spatial streams and support for the 6 GHz band, it offers interference-free connectivity, ensuring fast and reliable WiFi even in crowded spaces.
The access point provides extensive coverage of up to 140 m² (1,500 ft²) and can support over 300 connected devices simultaneously. This makes it an ideal solution for high-density environments where robust and consistent wireless performance is essential.
Powered using PoE+, this access point simplifies installation and reduces the need for additional power sources. It also features a 2.5 GbE uplink, ensuring a high-speed, stable connection to your network infrastructure for optimal data throughput.
Ubiquiti UniFi U7-PRO - Technical Specifications
Mechanical
- Dimensions Ø206 x 46 mm (Ø8.1 x 1.8")
- Weight 680 g (1.5 lb)
- Enclosure materials Polycarbonate, metal
- Mount material Mounting bracket: stainless steel (SUS304)
- Backing plate: galvanized steel (SGCC)
Hardware
- Networking interface (1) 2.5 GbE RJ45 port
- Management interface Ethernet
- Power method PoE+
- Power supply UniFi PoE switch
- Supported voltage range 44—57V DC
- Max. power consumption 21W
- Max. TX power
- 2.4 GHz 22 dBm
- 5 GHz 26 dBm
- 6 GHz 23 dBm
- MIMO
- 2.4 GHz 2 x 2
- 5 GHz 2 x 2
- 6 GHz 2 x 2
- Throughput rate
- 2.4 GHz 688 Mbps
- 5 GHz 2882 Mbps
- 6 GHz 5765 Mbps
- Antenna gain
- 2.4 GHz 4 dBi
- 5 GHz 6 dBi
- 6 GHz 5.8 dBi
- LEDs White/blue
- Button Factory reset
- Mounting Wall/ceiling (Included)
- Operating temperature -30 to 60° C (-22 to 140° F)
- Operating humidity 5 to 95% noncondensing
- Certifications CE, FCC, IC
Software
- WiFi standards 802.11a/b/g/n/ac/ax/be
- Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
- BSSID 8 per radio
- VLAN 802.1Q
- Advanced QoS Per-user rate limiting
- Guest traffic isolation Supported
- Concurrent clients 300+
Supported Data Rates
- 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11b 1, 2, 5.5, 11 Mbps
- 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
- 802.11ac (WiFi 5) 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
- 802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
- 802.11be (WiFi 7) 7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)
Application Requirements
- UniFi Network Version 8.0.7 and later
- UniFi OS Version 3.2 and later
